    Steel Continuous Coil Coating Line Furnace 300000ton/Year

    Excellent aluminum coil coating line for aluminium coil

    with foil rolls, rcuring furnace, etc.


    As aluminium is supplied cold rolled, it is usually supplied unlevelled (unlike steel which is often levelled in the galvanising line before colour coating), . It is therefore common to see tension levelling in the continuous process sections of aluminium coil coating lines. This avoids marking due to stopping / starting of the strip in the levelling machine and ensures optimum surface flatness and condition prior to coating


    Once again due to aluminium’s surface sensitivity and the soft alloys a 6 high levelling roll cassette is required.

    This design avoids any ‘tram-lining’, a marking problem that can be seen on the strip (and potentially through the colour coated product) created by back up rolls contacting the works rolls, which is eliminated by use of the 6 high machine design by the addition of intermediate rolls.

    Strip Cleaning (Cleaning Sections) and Pre-treatment


    In general, cleaning sections for steel and aluminium are similar if not the same in construction. Aluminium is usually supplied oiled but often this is dry and easily removable with alkali based cleaner. Many older aluminium coil coating lines were set up with only one tank, however, an additional tank combined with hot rinses and a well-designed cascade system can both limit water consumption and volume of effluent requiring water treatment prior to disposal. The major difference in an aluminium cleaning seciton is the absence of a brush scrubber that is more typically required for cleaning steel.


    Today, many pre-treatment chemicals are universal for both steel and aluminium and a move to chrome free products is being driven by environmental legislation. The use of roll coaters can allow for improved chemical application, reducing chemical consumption and provides a more accurate coating. With both roll coating and spray / squeegee systems dry-in-place chemicals are preferred today. This avoids any post rinsing again reducing effuent levels from the line and environmental impact.


    Technical Parameter
    Materialgalvanized steel strip or common steel steel strip
    Line speedwhole line speed 40-150m/min
    End product weight3,500-15,000kg/coil
    Outer Dia. of coilφ900-1,800mm
    Inner Dia. of coilφ508/φ610mm
    Thickness of steel strip0.2-1.2mm
    Width of steel strip600-1,250mm
    Energyproduce gas/natural gas/blast furnace gas,steam and electricity
    Thickness of color plate

    thickness of the frontsingle layer dry film can be adjusted between 10-20μm

    thickness of the reverse single layer dry film can beadjusted between 5-10μm

    Color plate qualitycomply with the requirement ofnational standard GB/T12754-2006
    Coiling staggered layerone side≤1.0 mm
